Specification

Dimension 2,700(L) x 1,020(W) x 2,245(H)mm
Weight 1800kg
Power AC220, 380, 400V / 50, 60Hz / 3Ph
Power Consumption 22KW
Die Roll Size Ø150 x 250mm
Die Roll Speed 3RPM (Maximum)
Compressed Air 5kg f/cm2

Olus Features

  • Process Patent registered in the U.S.A., New Zealand, South Africa and EU
  • Patent for raw materials of Olus capsules registered and publicly disclosed in Korea and the U.S.A.
  • Productivity improved by exceeding 3RPM
  • Stability verified with 20 machines currently being operated around the world, including 2 in Korea
  • Compatible with gelatin capsules

Production Capacity (3RPM)

Shapes & Sizes No. of Cavities Capsules/Hour
Oval#7.5 420 59,400
Oval#10 396 57,420
Ob#20 231 32,760
